Dostmann electronic LOG220 PDF Data Logger – Temperature, Humidity, Pressure

Dostmann electronic LOG220 PDF Data Logger for Temperature, Humidity and Air Pressure

The LOG220 belongs to the Dostmann electronic LOG200 series of PDF data loggers. It records, displays and monitors with alarms the temperature, relative humidity, dew point and barometric pressure. According to the manufacturer, areas of application include the monitoring of storage and transport conditions and of other temperature-, moisture- and/or pressure-sensitive processes.

The logger is delivered preset and can be used immediately without any software: recording is started with a button, and when the logger is plugged into a USB port it stops and creates a PDF report with configuration, summary, graph and alarm status by itself (this can take up to 40 seconds). The built-in USB connector fits Windows PCs, Apple computers or tablets without a cable (a USB adapter might be required). Recording interval, alarm limits, start and stop conditions and the internal clock are set with the free LogConnect software from the manufacturer.

The LCD shows air pressure in the first measurement line and humidity, temperature and dew point alternately in the second; a third line indicates MIN, MAX and AVG values, and the bottom status line shows battery capacity, logger mode and alarm status. A green LED flashes every 30 seconds during recording, a red LED and an internal buzzer signal limit alarms.

Key Features

• Temperature measuring range -40 to +70 °C, resolution 0.1 °C
• Relative humidity measuring range 0 to 100 %rH, resolution 0.1 %rH
• Air pressure measuring range 300 to 1100 hPa, resolution 0.1 hPa
• Dew point display and recording
• Memory for 60,000 data sets (temperature, humidity, pressure, dew point and motion)
• Integrated USB interface with automatic PDF report; the logger appears on the computer as a removable drive
• Ready to use without software: factory recording interval 5 minutes, start by button, stop by USB connection
• Free LogConnect software for configuration: interval, alarm levels, start delay, clock, display on/off
• High and low alarm limits with red LED, buzzer and alarm mark on the display and in the PDF report
• Motion detection: the PDF report shows whether and when the logger has been moved
• MIN / MAX / AVG values and event markers set with the MODE button
• Power-save mode: the display switches off after 2 minutes and is reactivated by moving the logger; recording continues
• Lockable wall holder
• Powered by one 3.6 V lithium ½ AA battery
• Accuracy as given in the previous product data: temperature from ±0.5 °C depending on the measuring range, humidity from ±3 %, air pressure from ±1 hPa
• Recording interval adjustable from 10 seconds to 24 hours with the LogConnect software
• Battery life approx. 4 years (recording interval longer than 15 minutes)

Package Contents

• Data logger LOG220
• Wall holder
• Battery 3.6 V (already inserted)
• USB protective cap
• 2 screws and dowels
• Factory certificate
