The SHAHE LXD-D is a portable digital Shore D durometer for hard rubber, rigid plastics and similar hard materials. It measures 0-100 HD (10-90 HD recommended) with a 2.5 mm indenter stroke and an SR0.1 mm tip, and shows the result on a large LCD with HOLD, ZERO and ON/OFF keys.
The SHAHE LXD-D is a digital Shore D durometer made by Wenzhou Sanhe Measuring Instrument Co., Ltd. It is intended for hardness testing of hard rubber, rigid plastics, acrylic, resins and similar hard materials, and gives a direct numerical reading on a large LCD instead of a dial pointer.
The tester covers a measuring range of 0-100 HD, with 10-90 HD recommended by the manufacturer for best results. The indenter has a stroke of 2.5 mm and an SR0.1 mm tip. The ZERO key resets the reading, HOLD freezes the value on the display, and ON/OFF switches the instrument on and off.
Its compact, firm body measures 115 × 60 × 25 mm, and the tester is delivered in a plastic carrying case, so it is easy to take from the laboratory to the production floor.
| Manufacturer | Wenzhou Sanhe Measuring Instrument Co., Ltd (SHAHE) |
|---|---|
| Model | LXD-D |
| Type | Digital Shore D durometer |
| Measuring Range | 0-100 HD |
| Recommended Measuring Range | 10-90 HD |
| Resolution | 0.5 HD |
| Indenter Stroke | 2.5 mm |
| Indenter Tip | SR0.1 mm |
| Indenter Cone Angle | 30° |
| Display | Large digital LCD |
| Keys | HOLD, ZERO, ON/OFF |
| Power Supply | 1.5V LR44 button cell battery |
| Dimensions | 115 × 60 × 25 mm |
| Country of Origin | China |
